Hook-up Wire 22AWG 1.37mm Tin Plated Copper 600VAC
| Specifications | |
|---|---|
| ECCN (US) | EAR99 |
| Part Status | Active-Unconfirmed |
| HTS | 8544.49.30.80 |
| Automotive | No |
| PPAP | No |
| Type | Hook-up Wire |
| Size (AWG) | 22 |
| Conductor Material | Tin Plated Copper |
| Maximum Outer Diameter (mm) | 1.37 |
| Maximum Voltage Rating | 600VAC |
| Insulation DC Resistance | 5000MOhm/1000ft |
| Maximum Operating Temperature (°C) | 150 |
| Bunch Stranding | 19x34 |
| Insulation Color | White |
